12V 30A DC to DC Charger

Product image 1
1 / 10
+5

12V 30A DC to DC Charger

With this 12V 30A DC DC Charger you can charge/maintain your auxiliary with the vehicles charging system.  Compatible with LiFePO4 Cells and other battery chemistries.

  • Strong Aluminium case with mounting brackets

  • 30A Charging current

  • 4 Stage high frequency Charging profile

  • Push button operation and compatible with AGM/Gel, Calcium, Lion, Lead-Acid Batteries

  • Temperature sensor which auto adjust power output

  • Protection for over charging, low voltage, short circuit and high temperature.

  • Reverse polarity protection for both input and outputs

  • Digital Display (Optional Extra)

Specification


Model: B2B1230
Type: Multi Stage DC to DC
Size: 190 x 194 x 70 (mm)
Weight 1.44kg
Input: DC Battery: 13.2-16.0 Volts
Output/Charging Voltage: 13.5-15.4 Volts(Stops charging when alternator output or vehicle battery below 13.0 volts)
Output Current: 30AMP
Minimum Start Voltage: 2.0 Volts-For battery being charged
Soft Start: Yes
Bulk Charge Voltage: (LiFePO4) 14.4V, (Flooded/AGM)14.7V, (Gel)14.3, (Sealed) 14.4V, (LiON - NCM)12.6V
Equalisation: Automatic
Float Charge Voltage: 13.5V(AGM/Gel)13.5V(Lead Acid)13.5V(Calcium)
Float Charge Current: 100mA
Battery Range: 18 to 250Ah
0-1 Metres Cable: 12AWG
1-5 Metres Cable: 8 AWG
5 Metres Cable: 6 AWG
Warranty covers manufacturing defects and is valid for 3 years from the date of purchase. The warranty does not include damage caused by misuse, accidental damage, or unauthorized repairs.

With this 12V 30A DC DC Charger you can charge/maintain your auxiliary with the vehicles charging system.  Compatible with LiFePO4 Cells and other battery chemistries.

  • Strong Aluminium case with mounting brackets

  • 30A Charging current

  • 4 Stage high frequency Charging profile

  • Push button operation and compatible with AGM/Gel, Calcium, Lion, Lead-Acid Batteries

  • Temperature sensor which auto adjust power output

  • Protection for over charging, low voltage, short circuit and high temperature.

  • Reverse polarity protection for both input and outputs

  • Digital Display (Optional Extra)

Specification


Model: B2B1230
Type: Multi Stage DC to DC
Size: 190 x 194 x 70 (mm)
Weight 1.44kg
Input: DC Battery: 13.2-16.0 Volts
Output/Charging Voltage: 13.5-15.4 Volts(Stops charging when alternator output or vehicle battery below 13.0 volts)
Output Current: 30AMP
Minimum Start Voltage: 2.0 Volts-For battery being charged
Soft Start: Yes
Bulk Charge Voltage: (LiFePO4) 14.4V, (Flooded/AGM)14.7V, (Gel)14.3, (Sealed) 14.4V, (LiON - NCM)12.6V
Equalisation: Automatic
Float Charge Voltage: 13.5V(AGM/Gel)13.5V(Lead Acid)13.5V(Calcium)
Float Charge Current: 100mA
Battery Range: 18 to 250Ah
0-1 Metres Cable: 12AWG
1-5 Metres Cable: 8 AWG
5 Metres Cable: 6 AWG
Warranty covers manufacturing defects and is valid for 3 years from the date of purchase. The warranty does not include damage caused by misuse, accidental damage, or unauthorized repairs.
