12V Triple Charger - AC-DC-DC with MPPT (Model: ABS126040)

The Ultimate 12V Multi-Source Charger – 60A DC-DC, 40A AC, 430W MPPT Solar

The ABS126040 12V Triple Charger is a game-changing, all-in-one battery charging solution designed for serious off-grid, RV, caravan, marine, and emergency power applications. This powerful charger integrates three independent charging sources—DC-DC from a vehicle alternator, AC-DC from mains power, and MPPT solar charging—ensuring reliable power anytime, anywhere.

Key Features & Benefits:

• Triple Charging Sources – Charge your 12V battery from a vehicle alternator (DC-DC), AC mains power (AC-DC), or solar panels (MPPT).
• 60A DC-DC Charging – High-power vehicle alternator charging with advanced voltage regulation to protect batteries and prevent over-discharge.
• 40A AC-DC Charging – Plug into 110V-240V AC mains for high-speed charging at home, in workshops, or at powered campsites.
• 430W MPPT Solar Charging – Built-in **MPPT controller** extracts maximum power from your solar panels, optimizing efficiency.
• Supports Lithium, AGM, Gel, and Lead-Acid Batteries – Selectable charge profiles ensure safe and efficient charging for all 12V battery types.
• Automatic Priority Switching – When AC power is available, it takes priority over solar and alternator charging.
• Smart Temperature & Voltage Sensing – Prevents overcharging, extends battery life, and maximizes efficiency.
• CANBUS & Bluetooth Connectivity – Monitor and configure the charger with an optional Bluetooth module or integrate it with CANBUS systems.
• Heavy-Duty Design – Rugged, compact, and designed for harsh environments with efficient cooling and protective circuitry.

Who Is It For?

• 4WD, RV, and Caravan Owners – Stay powered wherever you travel with **multiple charging options**.
• Off-Grid Enthusiasts – Perfect for remote cabins, outback setups, and **self-sufficient solar power systems**.
• Marine & Boating Users – Dependable **marine-grade power** for yachts, houseboats, and sailboats.
• Backup Power Solutions – Keep batteries fully charged for **emergency preparedness and blackout protection**.

Why Choose the ABS126040?

With no direct competitors, the ABS126040 Triple Charger is in a class of its own, providing **unparalleled charging flexibility, high efficiency, and intelligent battery management**. Whether you're off-grid, on the move, or at home, this charger delivers continuous, safe, and optimized power.



Technical Specifications

Feature	ABS126040
Input Voltage (DC-DC Charging)	10.5V - 16V
DC-DC Charging Current	60A
AC Input Voltage Range	90V - 270V AC (50/60Hz)
AC-DC Charging Current	40A
AC Charging Power	780W
Solar Input Power (MPPT)	430W
Solar Charge Controller Type	MPPT
Max. PV Open Circuit Voltage	50V
Max. Solar Charging Current	26A
Battery Compatibility	LiFePO4 (13.9V-14.6V), AGM, GEL, Lead-Acid
Battery Bank Voltage	12V
Recommended Battery Capacity	90Ah - 560Ah
Charge Stages	Boost, Absorption, Float
Charging Protection Features	Overvoltage, Overcurrent, Overheat, Reverse Polarity, Short Circuit
Start Battery Trickle Charge	0 - 5A
Bluetooth & CANBUS	Optional Bluetooth module & CANBUS for remote monitoring
Temperature Compensation	-3mV/°C/2V (for Lead-Acid only)
Cooling	Active cooling fan
Operating Temperature Range	-20°C to 50°C
Self-Consumption (Idle Mode)	28mA
Dimensions (L x W x H)	285mm x 234mm x 74mm
Weight	2.3kg
Mounting & Installation	Wall or panel mount with 20cm clearance for cooling

🚀 Power Your Journey with the ABS126040 – The Ultimate 12V Triple Charger! 🚀

See the Triple Charger User Manual here: User Manual

Warranty covers manufacturing defects and is valid for 3 years from the date of purchase. The warranty does not include damage caused by misuse, accidental damage, or unauthorized repairs.

Product FAQs

Q1: What is a 12V AC-DC-DC Charger with MPPT?

A 12V AC-DC DC charger with MPPT allows charging from three sources — vehicle alternator (DC-DC), mains power (AC-DC), and solar panels (MPPT). This makes it ideal for RVs, caravans, and off-grid battery systems.

Q2: Can this charger be used as a battery charger ac dc 12V at home?

Yes. It works as a reliable AC-DC charger for 12V batteries, making it suitable for home, workshop, or backup power applications.

Q3: What is the difference between a dc dc charger and this triple charger?

A standard DC-DC charger only uses alternator/DC input. This triple charger combines DC-DC, AC-DC, and solar MPPT charging in one unit, offering more flexibility and efficiency.

Q4: Is this dc to dc charger with MPPT compatible with LiFePO4 batteries?

Yes, it supports LiFePO4, AGM, and Gel batteries with optimized charging profiles, ensuring safe and efficient performance.

Q5: Is the 12V triple charger suitable for caravans and boats?

Absolutely. It’s designed for mobile and off-grid power needs, making it perfect for caravans, RVs, boats, and other 12V setups.

Q6: How long does it take to fully charge a 12V battery?

Charging time depends on battery size and condition, but with a 60A output, this charger provides fast and efficient charging compared to standard chargers.

Q7: Does the charger have built-in safety features?

Yes, it includes protection against overcharge, overcurrent, reverse polarity, and short circuits, ensuring safe long-term operation.

Q8: Can I monitor this charger remotely?

Yes. With the optional Bluetooth module and CANBUS integration, you can monitor and configure charging remotely using your device.
