Deye 8kW Single Phase Hybrid Inverter | SUN-8K-SG05LP1-AU
Deye 8kW Hybrid Inverter built for off-grid and hybrid solar systems. Features dual MPPTs, 190A battery charging, generator support, and up to 16kW solar PV access for homes, sheds, farms and larger backup power systems.
Deye 8kW Single Phase Hybrid Inverter SUN-8K-SG05LP1-AU
The Deye 8kW Single Phase Hybrid Inverter is a powerful solution for larger off-grid and hybrid solar systems. Ideal for homes, sheds, farms, workshops and backup power systems, it delivers strong 8kW output, flexible solar input and reliable battery integration for day and night power.
With support for lithium or lead-acid batteries, generator charging, AC coupling and parallel expansion, this inverter is a practical choice for customers wanting flexibility, backup capability and room to grow.
Best Suited For:
- Off-grid homes and larger residential systems
- Farms, sheds, workshops and rural properties
- Hybrid solar systems with battery backup
- Solar upgrades and retrofit projects
- Customers wanting generator backup support
Key Benefits:
- Powerful 8kW output for running larger household and property loads
- Up to 16,000W PV access power for substantial solar capacity
- 190A max charge and discharge current for efficient battery charging
- 2 MPPTs with 2+2 string design for flexible solar array layout
- Generator charging support for added backup security
- AC coupling capability for upgrading existing solar systems
- Parallel support for up to 16 units for larger system expansion
- IP65 weather protection suitable for indoor or outdoor installation
- Touch LCD display for simple setup and monitoring
- WiFi, RS485 and CAN communication for smart system monitoring
Technical Specifications:
| Model | SUN-8K-SG05LP1-AU |
| Battery Type | Lead-acid or Lithium-ion |
| Battery Voltage Range | 40–60V |
| Max Charge Current | 190A |
| Max Discharge Current | 190A |
| Max PV Access Power | 16,000W |
| Max PV Input Power | 12,000W |
| Max PV Input Voltage | 500V |
| Start-up Voltage | 125V |
| MPPT Voltage Range | 150–425V |
| Rated PV Input Voltage | 370V |
| Max Operating PV Input Current | 26 + 26A |
| Max PV Short-Circuit Current | 39 + 39A |
| MPPTs / Strings | 2 MPPT / (2+2) |
| Rated AC Output Power | 8,000W |
| Max AC Output Power | 8,000W |
| Rated AC Output Current | 34.8A |
| Max AC Output Current | 34.8A |
| Max AC Passthrough | 50A |
| Peak Off-Grid Power | 2× rated power for 10 seconds |
| Rated Voltage | 230V / 240V |
| Grid Frequency Range | 50Hz (45–55Hz) |
| Grid Connection | L + N + PE |
| Max Efficiency | 97.6% |
| Euro Efficiency | 96.5% |
| MPPT Efficiency | 99.9% |
| Protection Rating | IP65 |
| Cooling | Intelligent Air Cooling |
| Communication | RS485 / CAN |
| Monitor Mode | GPRS / WiFi / Bluetooth / 4G / LAN (optional) |
| Operating Temperature | -40°C to +60°C (>45°C derating) |
| Noise Level | <30dB |
| Dimensions | 330 × 580 × 232 mm |
| Weight | 24.9 kg |
| Warranty | 10 Years |
| Grid Regulation | AS/NZS 4777.2 |
| Safety Standards | IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
Why Choose This Inverter?
If you need a reliable inverter for a larger off-grid or hybrid setup, the Deye 8kW Single Phase Hybrid Inverter offers strong solar input, fast battery charging, generator support and flexible system expansion. It is a smart choice for dependable long-term energy independence.
