Enerlution 5.12 kWh Wall Mounted Solar Battery Storage - LFPWall-5000
Introducing the Enerlution 5.12 kWh Wall Mounted Solar Battery Storage - LFPWall-5000, a cutting-edge energy storage solution designed to meet the demands of modern energy management. Perfect for residential and small commercial applications, this powerful lithium iron phosphate (LiFePO4) battery system delivers dependable performance, safety, and efficiency for a variety of energy storage needs.
Key Features:
- Impressive Energy Capacity: With a rated energy of 5.12kWh, the LFPWall-5000 ensures ample storage for your daily electricity needs, whether for solar energy integration or backup power supply.
- Enhanced Performance: Operating within a battery voltage range of 45-57.6V and featuring a rated voltage of 51.2V, this battery is designed for optimal efficiency and reliability.
- Scalable Solution: Supports connection of 1-8 modules in parallel, allowing customization and scalability based on energy requirements.
- Long Lifecycle: Capable of achieving a cycle life of over 6000 cycles at 25°C, 0.5C, providing long-term reliability and durability.
- Advanced Safety: LiFePO4 chemistry offers superior thermal stability and safety compared to traditional lithium-ion batteries, reducing the risk of overheating or combustion.
Applications:
- Home Energy Storage: Ideal for integrating with residential solar systems to store excess energy for later use, minimizing reliance on grid electricity.
- Backup Power Systems: Provides reliable backup power during outages, ensuring critical household appliances continue to function without interruption.
- Off-Grid Solutions: Suitable for off-grid applications, delivering consistent, renewable energy support for remote locations or sustainable living communities.
Benefits:
- High Efficiency: Achieves up to 90% depth of discharge (DOD), maximizing usable energy and providing more efficient energy use.
- Robust Communication Options: Equipped with CAN and RS485 communication protocols for seamless integration with energy management systems.
- Temperature Resilience: Operates efficiently in a wide working temperature range, ensuring consistent performance under various environmental conditions.
- Compact and Lightweight Design: With product dimensions of 536.3464180.5mm and a net weight of 48.5kg (106lb), the LFPWall-5000 fits conveniently into compact spaces and is easy to handle during installation.
Technical Specifications:
| Specification | Details |
|---|---|
| Model | LFPWall-5000 |
| Rated Capacity | 100 Ah |
| Rated Energy | 5.12 kWh |
| Rated Voltage | 51.2 V |
| Battery Voltage Range | 45 - 57.6 V |
| Max. Charging Current | 45 A |
| Max. Discharging Current | 75 A |
| Battery Type | LiFePO4 |
| Max. Output Power | 3840 W |
| Depth of Discharge (DOD) | 90% |
| Modules Connection | 1-8 in parallel |
| Communication | CAN, RS485 |
| Cycle Life | ≥ 6000 @ 25°C, 0.5C |
| Working Temperature Range | Charge: 0°C ~ +50°C |
| Discharge: -10°C ~ +55°C | |
| Storage Temperature | -20°C ~ +35°C |
| Net Weight | 48.5 kg / 106 lb |
| Gross Weight | 52.5 kg / 115 lb |
| Product Dimension (WHD) | 536.3 * 464 * 180.5 mm |
| Package Dimension (WHD) | 592 * 522 * 252 mm |
| Warranty | YES |
Embrace the future of energy storage with the LFPWall-5000, your go-to solution for reliable, safe, and efficient energy management.
